    Automatic Control Ladle Refining Furnace LF Furnace with Tubular Water Cooled Lid and Electrode Lifting Mechanism

    Ladle Refining Furnace

    Ladle Refining Furnace 10T-160T LF with Competitive and 380V Voltage

    Product introduction

    Ladle Refining Furnace is used to refine the molten steel from primary melting furnace (electric arc furnace, induction furnace, converter and etc.), meanwhile have the function of adjusting molten steel temperature, and be a buffer of the whole process. It is described to be soul of the best production line ( primary melting furnace + LF+ CCM). It is widely used in refining of kinds of steel grade, such as Ball bearing steel, alloy structural steel, tool steel, spring steel, carbon steel and etc.

    Characteristic:

    1. Even the molten steel composition and temperature

    2. Desulfidation, Degassing, deoxidation and remove non-metallic impurities.

    3. Increase production capacity.

    Adoption of new technology:

    1. Tubular water cooled furnace lid

    2. Electrode lifting mechanism ( single phase, three phase)

    3. Optimize large current system structure (energy-saving type)

    4. PLC controller of electrode automatic lifting regulator

    5. Automatic control argon blowing system

    6. Frequency control ladle car

    7. Industrial automatic control

    8. Network technique

    Main Technical Specifications:

    LadleRated Capacity (ton)

    Ladle Diameter (mm)

    Transformer Rated Capacity (KVA)

    Electrode Diameter (mm)

    Electrode distribution circle Diameter (mm)

    Molten steel Temperature raising speed (Co /min)

    20

    2200

    3150

    200

    500

    2-3

    40

    2900

    6300

    350

    650

    2-3

    60

    3100

    10000

    350

    650

    2-3.5

    70

    3200

    12500

    400

    700

    2-3.5

    100

    3400

    18000

    400

    700

    2-3.5

    150

    3900

    20000

    450

    800

    2-3.5
