    10T-150T Capacity Electric Arc Furnace with PLC Control System for Precise Temperature Control in Steel Melting

    Ask Lasest Price
    Brand Name : AE
    Certification : CE;ISO9001;ISO14001;OHSAS 18001
    Price : Negotiation
    Delivery Time : 30-60 work days
    • Product Details
    • Company Profile

    10T-150T Capacity Electric Arc Furnace with PLC Control System for Precise Temperature Control in Steel Melting

    Electric Arc Furnace (EAF) for Steel Melting - 10T-150T Capacity
    The Electric Arc Furnace utilizes electricity as its fuel source, generating high-temperature arcs between electrodes and furnace charge for efficient metal melting. This industrial-grade equipment is essential for producing various steel grades including carbon steel, alloy steel, stainless steel, and ferroalloys in steel mills, foundries, and alloy production facilities.
    Key Features and Advantages
    • Precise temperature control adaptable to different steel grade requirements
    • High thermal efficiency with controllable furnace atmosphere
    • Effective removal of phosphorus, sulfur, oxygen and other impurities
    • Precise chemical composition control with high alloy recovery rates
    • Simplified equipment design with streamlined production process
    Advanced Technological Features
    • Optimized structural design for maximum efficiency
    • Tubular water-cooled furnace wall and lid system
    • Eccentric Bottom Tapping (EBT) technology
    • Copper-steel composite electrode arms
    • Cluster-type large sectional area water-cooled cables
    • Energy-saving optimized large current system
    • Proportional valve hydraulic system
    • PLC + Industrial computer control system
    • Advanced frequency control and network technology
    Complete System Components
    The furnace system includes: furnace body, tilting mechanism, furnace cover, furnace bracket, cover lifting/rotating mechanism, electrode lifting mechanism, short net system, cooling system, air compression system, upright bracket, maintenance platform, electrode extension device, hydraulic system, transformer, oxygen lance devices (furnace door and cluster), high voltage cabinet, low voltage power supply system, and computer/PLC control system.
    Technical Specifications
    ModelRated Capacity (T)Max Capacity (T)Furnace Shell Inner Diameter (MM)Electrode Diameter (MM)Transformer Capacity (KVA)
    EAF-5T51032003002500-4300
    EAF-10T101836003505500-8000
    EAF-15T152438003508000-12500
    EAF-20T203040004009000-12500
    EAF-25T2535420040012500
    EAF-30T3045440040012500-25000
    EAF-40T4055460045016000-30000
    EAF-45T4565480045016000-40000
    EAF-60T6085540050025000-60000
    EAF-80T80100610050030000-80000
    EAF-100100120640055040000-80000
